NetApp FAS3050 Filer Head Single Controller

Part#:
FAS3050
Brand:
NetApp
Type:
Filer Head
Condition:
ECS Refurbished & Tested

-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.

NetApp FAS3050 Enterprise Storage System

Maximum Raw Capacity (HA): 168TB
Maximum Disk Drives: 336
Maximum Internal Drives: 14
Controller Form Factor: 3U
Max Memory: 8GB
Disk Type: Fibre Channel, SATA
Disk Form Factor:3.5"
Host Connectivity: 2Gb Fibre Channel (FC), 1GbE
Storage Protocols Supported: CIFS (NAS), Fibre Channel (FC), iSCSI (IP SAN), NFS (NAS)
Supported RAID: RAID 4, RAID 6 (RAID-DP)

*Available in Single or Dual Controller ('C' Cluster / 'A' Active-Active / 'HA' High-Availability). Call for Details and Pricing

The FAS3050 is an exceptional value mid-level storage system that is versatile, scalable and reliable for both SAN and NAS applications and consolidations. The FAS3000 series is fully compatible with the broad family of NetApp FAS systems, which meet a range of storage needs from small remote office and departmental applications through the largest enterprise application and consolidations.

With its large cache memory configurations, expandable high-performance I/O, 4Gb FC SAN support, and support for 10GbE, the FAS3050 delivers exceptional midrange systems performance. The FAS3050 comes with SnapShot which provides superior availability along with storage resiliency features, and disaster recovery options. Resilient features such as RAID-DP (High-performance RAID6 ), ensures that the FAS3050 storage system is always up and running.

The FAS3050 can use both high-performance Fibre Channel and low-cost SATA disk drives for primary and secondary storage while seamlessly consolidating block and file storage on the same system. This is made possible through the native support of the FCP, iSCSI, NFS, and CIFS storage protocols via Fibre Channel or Ethernet interfaces.

FAS3050 Technical Specifications

TECHNICAL SPECIFICATIONS FOR SINGLE AND HA CONFIGURATIONS
Maximum Raw Capacity (HA) 168TB
Recommended Min Raw Capacity Array LUNs (GB) N/A
Absolute Min Raw Capacity Array LUNs (GB) N/A
Maximum Storage Devices (HA) 336 Disks
Max DS2246 Shelves (HA) N/A
Max DS4243 Shelves (HA) N/A
Max DS4246 Shelves (HA) N/A
Max DS4486 Shelves (HA) N/A
Max DS14-Class Shelves (HA) 24
Max Nodes per Cluster (NAS) Not Supported
Max Nodes per Cluster (SAN) Not Supported
Aggregate Size 32 bit (TiB) 16
Aggregate Size 64 bit (TiB) N/A
Min Size for an Array LUN Aggregate (GB) N/A
Flex Volume Size 32 bit (TiB) 16
Flex Volume Size 64 bit (TiB) N/A
Max Infinite Volume Data Constituent Size (TiB) Not Supported
Max Volume Count (Single) 200
Max Array LUN Size (GB) N/A
Min Array LUN Size (GB) N/A
Min Array LUN Size - Root Volume (GB) N/A
Min Root Volume Size (Single/HA) 20GB / 20GB
Spare Core Array LUN Min Size (GB) N/A
Max RAID Groups in an Aggregate N/A
Block Size (Bytes) N/A
Chassis Height 5.12"
Chassis Width 17.72"
Chassis Depth 23.90"
Rack Units (Single/HA) 3U/6U
Operating Temperature Range 50°F to 104°F
Storage Temperature Range -40° to 149°F
Input Power Voltage 100v to 120v, 200v to 240v
Processor (Single) 2x 32-bit 2.80Ghz
Memory (Single/HA) 4GB/8GB
NVRAM (Single) 512MB (Adapter Card)
Ethernet Ports (Single) 4x RJ45 (1Gbps)
Fibre Channel Ports (Single) 4x SFP (2Gbps)
UTA2 Ports (Single) N/A
Expansion Slots (Single) 4x PCI-X
SAS Ports (Single) N/A
Max Back-End FC Loops (HA) 8
Min Version of Data ONTAP 7 7.2
Min Version of Data ONTAP 8 (both modes) N/A
Max Version of Data ONTAP 8 (both modes) N/A

Ask about our NetApp Disk Shelves! We can create custom Turn-Key configurations based on your needs!
