HPE ProLiant DL380 Gen10 8LFF Server Chassis | 868706-B21


Price: Request a Quote

Brand:
MPN:
868706-B21
Type:
Chassis
Condition:
ECS Refurbished & Tested

Request Quote

Note: Please include as much details and relevant options about the item to help us match your request with an accurate price.


-PLEASE CONTACT FOR CUSTOM CONFIGURATIONS. DISK SHELVES, COMPLETE CONFIGURATIONS & TURN KEY SYSTEMS AVAILABLE.
-SPARE PARTS AVAILABLE FOR EACH MODEL. PLEASE ASK FOR PRICING ON SPARE DISK, CONTROLLERS, POWER SUPPLIES, NICs, HBAs, SFPs, Cables, etc.

HPE ProLiant DL380 Gen10 8LFF Server Chassis | 868706-B21

CTO Server [Chassis] HPE ProLiant DL380 Gen10 8LFF CTO Server HPE ProLiant DL380 Gen10 12LFF CTO Server HPE ProLiant DL380
Gen10 8SFF CTO Server
HPE ProLiant DL380 Gen10 24SFF CTO Server HPE DL380 Gen10 8SFF BC CTO Server
SKU Number 868706-B21 868705-B21 868703-B21 868704-B21 P56970-B21
Processor Not included as standard
DIMM Slots 24-DIMM slots
Storage Controller Embedded SW RAID with 14 SATA ports (12-ports accessible), choice of HPE modular Smart Array and PCIe plug-in controller
PCIe Three standard in primary riser (with dual M.2 support)
Drive Cage - included 8 LFF 12 LFF 8 SFF 24 SFF 8 SFF
Network Controller HPE 1Gb Ethernet 4 - Port 331i Adapter plus optional HPE FlexibleLOM or stand up card
Fans 6-Standard 6-Performance 4-Standard 6-Performance 4 - Standard
USB 1x 3.0 standard plus iLo front service port None as standard 1x 3.0 standard plus iLo front service port 1x 3.0 standard plus iLo front service port 1x 3.0 standard plus iLO front service port

Refurbished HPE ProLiant DL380 Gen10 8LFF Server Chassis | 868706-B21

The refurbished HPE ProLiant DL380 Gen10 server delivers the latest in security, performance and expandability, backed by a comprehensive warranty. Standardize on the industry's most trusted compute platform. The HPE ProLiant DL380 Gen10 server is securely designed to reduce costs and complexity, featuring the First and Second Generation Intel Xeon Processor Scalable Family with up to a 60% performance gain and 27% increase in cores, plus the HPE 2933 MT/s DDR4 SmartMemory supporting 3.0 TB.

It supports 12 Gb/s SAS, and up to 20 NVMe drive plus a broad range of compute options. HPE Persistent Memory offers unprecedented levels of performance for databases and analytic workloads. Run everything from the most basic to mission-critical applications and deploy with confidence.

What’s New for DL380 Gen10

  • Increased Single-Width GPU Density with up to 7 NVIDIA T4 in a 2U, standard length, rackmount server.
  • HPE DL38x Gen10 x16/x16/x16 Primary (P14374-B21) and Secondary (P14373-B21) Risers support up to (7) NVIDIA T4 16GB ; or up to (6) NVIDIA T4 16GB balanced across both processors with additional options for PCIe card expansion.
  • Networking Choice (NC) server models provide greater flexibility in the primary networking selection.
  • Supporting the second generation Intel Xeon Scalable processor family with up to a 11% per-core performance gain over first generation and with memory speeds up to 2933 MT/s.
  • HPE Persistent Memory offers the flexibility to deploy as dense memory or fast storage using Intel Optane DC Persistent Memory and enables per-socket memory capacity of up to 3.0 TB.
  • iLO 5 security enhancements: Server Configuration Lock, iLO Security Dashboard and Workload Performance Advisor. HPE InfoSight provides cloud-based analytics to predict and prevent issues proactively.

Flexible Design Making Your Investment Expand As Your Business Needs Grow

The HPE ProLiant DL380 Gen10 server has an adaptable chassis, including new Hewlett Packard Enterprise modular drive bay configuration options with up to 30 SFF, up to 19 LFF or up to 20 NVMe drive options along with support for up to three double wide GPU options.

HPE Persistent Memory works with DRAM to provide fast, high capacity, cost effective memory and storage to transform big data workloads and analytics by enabling data to be stored, moved, and processed quickly.

In conjunction with the embedded SATA HPE Dynamic Smart Array S100i Controller for boot, data and media needs, the redesigned HPE Smart Array Controllers allow you the flexibility to choose the optimal 12 Gb/s controller most suited to your environment, and operate in both SAS and HBA mode.

Along with an embedded 4x1GbE, you have a choice of HPE FlexibleLOM or PCIe standup adapters which offer a choice of networking bandwidth (1GbE to 40GbE) and fabric so you can adapt and grow to changing business needs.


Know your Server - CTO Configuration Support

Need help with the configuration? Contact us today!

This Product Is Compatible With The Following Systems:

Product Specs

Base Standard Capabilities

Technical specificationsHPE ProLiant DL380 Gen10 server
Processor nameIntel
Processor familyIntel® Xeon® Scalable 8100/8200 series Intel® Xeon® Scalable 6100/6200 series Intel® Xeon® Scalable 5100/5200 series Intel® Xeon® Scalable 4100/4200 series Intel® Xeon® Scalable 3100/3200 series
Processor core available4 to 28 core, depending on model
Processor cache8.25 - 38.50 MB L3, depending on processor model
Processor speed3.9 GHz, maximum depending on processor
Expansion slots8, for detailed descriptions reference the QuickSpecs
Maximum memory3.0 TB with 128 GB DDR4, depending on processor model
6.0 TB with HPE 512GB 2666 Persistent Memory Kit, depending on processor model
Memory, standard1.54 TB (24 X 64 GB) RDIMM
3.0 TB (24 X 128 GB) LRDIMM
6.0 TB (12 X 512 GB) Persistent Memory
Memory slots24 DIMM slots
Memory typeHPE DDR4 Smart Memory with optional Intel® Optane™ persistent memory 100 series for HPE, depending on processor model selected. Intel Optane Persistent Memory for HPE only supported on select 2nd Generation Intel Scalable Series Processors, to include: 82xx, 62xxR, 62xx, 52xxR, 52xx series processors, and the 4215R and 4215 processors.
System fan featuresHot-plug redundant fans, standard
Network controllerHPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional HPE FlexibleLOM, depending on model
Storage controller1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1 HPE Smart Array E208i-a, depending on model
Product Dimensions (imperial)17.54 x 28.75 x 3.44 in
Weight32.6 lb
Infrastructure managementHPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, and HPE OneView Advanced (optional requires licenses)
Drive supported8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD
2 M.2 SATA SSD standard on primary riser, depending on configuration
6 SFF rear drive optional or 3 LFF rear drive optional and 2 SFF or 2 Dual UFF rear drive optional
20 SFF NVMe optional
NVMe support via Express Bay will limit maximum drive capacity
