HPE ProLiant DL180 Gen9 Hot Plug 12LFF Server Chassis | 775506-B21

ECS Refurbished & Tested

Request Quote

Note: Please include as much details and relevant options about the item to help us match your request with an accurate price.

*Adds to cart & you can request a quote from the cart page

CTO Server [Chassis] HPE ProLiant DL180
Gen9 Non-hot Plug 4LFF
Configure-to-order Server
HPE ProLiant DL180
Gen9 Hot Plug 8LFF
HPE ProLiant DL180
Gen9 Hot Plug 8SFF
HPE ProLiant DL180
Gen9 Hot Plug 12LFF
SKU Number 754525-B21 754524-B21 754523-B21 775506-B21
Processor 2 (optional) x HPE Smart Socket Guide
DIMM Slots 16 DIMM slots for RDIMM, LRDIMM DDR4 Memory
Storage Controller HPE Dynamic Smart Array B140i
PCIe 3 PCIe slots (+3 PCI slots available with upgrade option, second processor required)
Drive Cage - included 4LFF or 8LFF Non Hot
8LFF Hot Plug (+4LFF
optional field
8SFF Hot Plug (+8SFF
12LFF Hot Plug
Network Controller HPE Ethernet 1Gb 2-port i350 Adapter
Fans 2 hot swap fans, non-redundant
USB 1 front, 1 internal, 2 rear
Ears Optional HPE Quick Release Ears HPE Thumbscrew Ears HPE Quick Release Ears

HPE ProLiant DL180 Gen9 Hot Plug 12LFF Server Chassis | 775506-B21

Designed with just the right balance of scalability and performance, therefurbished HP ProLiant DL180 Gen9 Server is an optimized 2U model that helps growing businesses, data centers, and service providers alike manage their infrastructures more efficiently. With high availability and efficiency for dense storage applications, this server allows for more agile management that enables accelerated service delivery.

What's New for DL180 Gen9

  • Intel Xeon E5-2600v4 processor support (Up to 120 W)
  • New 900 W/240 V power supply
  • HPE Trusted Platform Module (TPM) 2.0
  • New HDD offerings
  • Support for ClearOS – an easy to use OS with an application marketplace

Scalability and Performance To Meet the New Standard of Growing Data Center Needs

The HPE ProLiant DL180 Gen9 Server provides ample storage capacity on demand with drive configurations ranging from (4) to (12) Large Form Factor (LFF) or (8) to (16) Small Form Factor (SFF) HPE SmartDrives, with flexibility of LFF non-hot plug (NHP) options at the right economics.

It supports up to two Intel Xeo processor E5-2600 v3/v4 processors with up to (12) cores and (16) DIMM slots of HPE DDR4 SmartMemory offering improved performance and efficiency.

Comes standard with 2x1GbE and choice of HPE FlexibleLOM or PCIe standup 1GbE or 10GbE Adapters provide you flexibility of networking bandwidth and fabric so you can adapt and grow to changing business needs.

Up to six PCIe 3.0 riser slots to support a wide range of GPUs and networking cards offering increased IO bandwidth and seamless expandability.

Embedded SATA HPE Dynamic Smart Array B140i Controller for boot and data. Choice of HPE Smart Array Controllers with increased performance, data availability with 12 Gb/s SAS technology or HPE Smart HBAs with reliable high performance SAS connectivity capable of running HBA mode or simple RAID mode.

Know your Server - CTO Configuration Support

Need help with the configuration? Contact us today!

Product Specs for HPE 775506-B21

More Specs

Technical specifications HP ProLiant DL180 Gen9 Server
Compute Up to 2 Intel® Xeon® E5-2600 v3 Series, 4/6/8/10/12 Cores, PCIe 3.0, up to 6 available slot(s)
Memory HP SmartMemory (16) DDR4, up to 2133 MHz (512 GB max)
Storage Standard HP Dynamic Smart Array B140i, optional HP Smart Array Controllers, and HP Smart HBAs via PCIe stand-up cards
Battery HP DL/ML/SL 96 W Smart Storage Battery to support the standup controllers
HP SmartDrives 16 SFF/12 LFF max, HDD/SSD
Networking Embedded 2x 1GbE, optional FlexibleLOM slot on riser
VGA/serial/USB ports/SD 1 VGA, 1 Serial, 6 USB 3.0, 1 microSD
GPU Support Single-Wide and Active
On Premise management HP OneView and HP iLO Advanced
On Cloud management HP Insight Online with enhanced mobile application
On System management HP iLO, HP SUM, Intelligent Provisioning and scripting tools; plus the new UEFI and HP RESTful Interface Tool
Power and cooling Up to 94 percent efficient (Platinum), 550 W multi-output, 900 W RPS1 Hot swap fans with optional redundancy
Industry compliance ASHRAE A3 and A4, ENERGY STAR®
Form factor/Chassis depth ASHRAE A3
Form factor/chassis depth Rack (2U), 23.9" (SFF), 23.9" (LFF)
Serviceability — Easy install rails Standard

Spec Sheet

Technical Guide
