HPE ProLiant DL385p Gen8 CTO Server

Part#:
DL385PG8
Brand:
HPE
Type:
CTO Servers
Condition:
ECS Refurbished & Tested
Warranty:
ECS 1 Year Hardware Warranty

READ ME

  • Some options may not be displayed until the compatible parent option is chosen ie. Chassis – Drives, Processor – RAM etc.
  • “Submit for Quote” items can be added to your cart and sent to us via the cart page
  • Click the blue bar to close/open a section from view after choosing your options

Server Chassis

Processors

AMD Opteron 6300 Series

Supports up to (2) processors - View product features for supported memory

HPE Memory

HPE RAID Controllers

HPE SFF Drives SAS (2.5in)

HPE SFF Drives SATA (2.5in)

HPE LFF Drives SAS (3.5in)

HPE LFF Drives SATA (3.5in)

HPE PCIe Drives

6 PCIe Slots (Full Height)

HPE Network Adapters

6 PCIe Slots (Full Height)

HPE Host Bus Adapter

6 PCIe Slots (Full Height)

HPE FlexibleLOM Adapter

HPE InfiniBand Adapter

6 PCIe Slots (Full Height)

HPE Power Supplies

Supports up to (2) PSU's

HPE Options

HPE Rail Kits

HPE Optical Drives

HPE Security

ECS Warranty

HPE DL385p Gen8 Rack Server Product Description

The HP ProLiant DL385p Gen8 Server series sets the flexible standard for next generation AMD rack servers. With designed-in quality and serviceability, performance and enhanced configuration flexibility, this customer-inspired design offers the perfect solution for virtualization, database, and dynamic computing workloads.

What's New for DL385p Gen8

  • Support for 1.2TB SFF 6G SAS10K Enterprise, 4TB LFF 3G SATA 7.2k Midline; and up to 800GB SATA ME Hot Plug SFF/LFF Enterprise SSD drives.

DL385p Gen8 8SFF

DL385p Gen8 8SFF

DL385p Gen8 24SFF

DL385p Gen8 24SFF

DL385p Gen8 8LFF

DL385p Gen8 8LFF

DL385p Gen8 12LFF

DL385p Gen8 12LFF

Improved Performance and Capacity for Compute, Storage

AMD Opteron 6300 Series Processors, providing new levels of performance and efficiency over the previous generation.

HPE SmartMemory prevents data loss and downtime with enhanced error handling while improving workload performance and power efficiency.

HPE SmartDrive technology improves serviceability and prevents data loss with features such as icon-based status display and do-not-remove LED.

DL385p Gen8 rear

DL385p Gen8 rear

Product features

Feature
Description
Processor (One of the following depending on Model)
  • AMD Opteron 6386SE (2.8 GHz/16-core/16MB/140 W TDP) Processor

  • AMD Opteron 6380 (2.5 GHz/16-core/16MB/115 W TDP) Processor

  • AMD Opteron 6378 (2.4 GHz/16-core/16MB/115 W TDP) Processor

  • AMD Opteron 6376 (2.3 GHz/16-core/16MB/115 W TDP) Processor

  • AMD Opteron 6366HE (1.8 GHz/16-core/16MB/85 W TDP) Processor

  • AMD Opteron 6284SE (2.7 GHz/16-core/16MB/140 W TDP) Processor

  • AMD Opteron 6282SE (2.6 GHz/16-core/16MB/140 W TDP) Processor

  • AMD Opteron 6278 (2.4 GHz/16-core/16MB/115 W TDP) Processor

  • AMD Opteron 6276 (2.3 GHz/16-core/16MB/115 W TDP) Processor

  • AMD Opteron 6274 (2.2 GHz/16-core/16MB/115 W TDP) Processor

  • AMD Opteron 6272 (2.1 GHz/16-core/16MB/115 W TDP) Processor

  • AMD Opteron 6262HE (1.6 GHz/16-core/16MB/85 W TDP) Processor

  • AMD Opteron 6348 (2.8 GHz/12-core/16MB/115 W TDP) Processor

  • AMD Opteron 6344 (2.6 GHz/12-core/16MB/115 W TDP) Processor

  • AMD Opteron 6238 (2.6 GHz/12-core/16MB/115 W TDP) Processor

  • AMD Opteron 6234 (2.4 GHz/12-core/16MB/115 W TDP) Processor

  • AMD Opteron 6328(3.2 GHz/8-core/16MB/115 W TDP) Processor

  • AMD Opteron 6320 (2.8 GHz/8-core/16MB/115 W TDP) Processor

  • AMD Opteron 6220 (3.0 GHz/8-core/16MB/115 W TDP) Processor

  • AMD Opteron 6212 (2.6 GHz/8-core/16MB/115 W TDP) Processor

  • AMD Opteron 6308 (3.5 GHz/4-core/16MB/115 W TDP) Processor

  • AMD Opteron 6204 (3.3 GHz/4-core/16MB/115 W TDP) Processor

Cache memory
16MB (2 x 8MB) Level 3
Chipset
AMD SR5690 Northbridge and SP5100 Southbridge
Upgradeability
  • Upgradeable to 2 processors

  • Up to 24 DIMM slots available for higher memory capacities

  • FlexibleLOM connector for 1Gb or 10Gb networking options

  • 8SFF (plus optional upgrade of 8SFF for up to 16SFF drives-requires second Smart Array) and other Models with 8LFF, 12LFF, or 25SFF hard drive bays

  • Optional 3-slot PCIe 2.0 riser (x16, x8, x8)

  • Redundant power supply

  • Optical drive (available on 8SFF and 8LFF Models only)

On system management chipset
HP iLO (Firmware: HP iLO 4)
Memory protection
  • Advanced ECC

  • Online spare

Memory (One of the following depending on Model)
DIMM Slots available
24 (12 DIMM slots per processor/4 channels per processor/3 DIMMs per channel)
Storage centric model
16GB (2 x 8GB) PC3-10600R (DDR3-1333) Registered DIMMS
Dedicated workload model
32GB (4 x 8GB) PC3-10600R (DDR3-1333) Registered DIMMS
Maximized consolidation model
32GB (4 x 8GB) PC3-10600R (DDR3-1333) Registered DIMMS
Maximum capacity (LDIMM)
768GB (24 x 32GB LRDIMM @ 800 MHz)
Maximum capacity (RDIMM)
128GB (8 slots x 16GB RDIMM @1600 MHz)
Network controller
HP Ethernet 1Gb 4-port 331FLR adapter
Graphics
Integrated Matrox G200 video standard
  • 1280 x 1024 (32 b/p)

  • 1920 x 1200 (16 b/p)

Storage controller (One of the following depending on Model)
Entry model
HP Smart Array P420i/ZM (RAID 0/1)
Storage centric model
HP Smart Array P420i/512MB FBWC (RAID 0/1/1+0/5/5+0)
Dedicated workload model
HP Smart Array P420i/1GB FBWC (RAID 0/1/1+0/5/5+0)
Maximized consolidation model
HP Smart Array P420i/2GB FBWC (RAID 0/1/1+0/5/5+0)
Optical drive
Optional: DVD-ROM, DVD-RW
Hard drives
None ship standard
Drive bays (One of the following depending on Model)
Entry model
8-SFF drive bays (additional 8-SFF option)
Storage centric model
12-LFF drive bays
Dedicated workload model
8-SFF drive bays total with options for DVD OR optional second 8-SFF drive bay set (total of 16SFF drive bays, no DVD)
Maximized consolidation model
25-SFF drive bays total
Maximum internal storage
Hot Plug SFF SAS
30.0TB
25 x 1.2TB (on 25 SFF Drive Bay Models)
Hot Plug SFF SATA
25.0TB
25 x 1TB (on 25 SFF Drive Bay Models)
Hot Plug LFF SAS
48.0TB
12 x 4TB (on 12 LFF Drive Bay Models)
Hot Plug LFF SATA
48.0TB
12 x 4TB (on 12 LFF Drive Bay Models)
Hot Plug SFF SAS SSD
20.0TB
25 x 800GB (on 25 SFF Drive Bay Models)
Hot Plug LFF SATA SSD
10.0TB
12 x 800GB (on 12 LFF Drive Bay Models)
Interfaces
Serial
1 (Back)
Video
2 (1 front, 1 back) not active simultaneously
SD Slot
1 Internal secure
USB 2.0 Ports
Up to 8 total: up to 2 front, 4 back, 2 internal
HP iLO Remote Management Network Port
1Gb Dedicated
FlexibleLOM Network Ports
All pre-configured models come standard with 4 x 1GB ports
Industry standard compliance
  • ACPI 2.0b Compliant

  • PCIe 2.0 Compliant

  • PXE Support

  • WOL Support

  • Microsoft Logo certifications

  • USB 2.0 Compliant

System fans (One of the following depending on Model)
  • 2P Models have (6) (N+1 redundancy standard)

  • 1P Models have (4) (N+1 redundancy standard)

Expansion slots
Expansion Slots
Technology
BusWidth
Connector Width
Bus Number
Form Factor
1
PCIe 2.0
x8
x16
5
Full length, Full height slot
2
PCIe 2.0
x8
x8
8
Half length, Full height slot
3
PCIe 2.0
x4
x8
11
Half length, Full height slot
Security
  • Power-on password

  • Administrator's password

  • Serial interface control

Form factor
2U Rack form factor

top


Software overview

Feature
Description
Operating systems and virtualization software support for ProLiant servers1
  • Microsoft Windows Server

  • Red Hat Enterprise Linux (RHEL)

  • SUSE Linux Enterprise Server (SLES)

  • VMware

  • Oracle Solaris

  • Citrix XenServer

NOTE: 1: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization Software and latest listing of software drivers available for the server. Click here to visit the Support Matrix .

top

Physical specifications

Specification
Description
Dimensions (H x W x D) (with bezel)
  • SFF Drives: 8.73 x 44.55 x 69.85 cm (3.44 x 17.54 x 27.50 in)

  • LFF Drives: 8.73 x 44.55 x 74.93 cm (3.44 x 17.54 x 29.50 in)

Weight (approximate)
  • Maximum (all LFF hard drives, power supply, and processor installed): 27.66 kg (61.00 lb)

  • Minimum (one SFF hard drive, power supply, and processor installed, ODD not installed): 18.59 kg (41.0 lb)

top

Electrical specifications

Specification
Description
Rated line voltage
  • 100 to 120 V ac

  • 200 to 240 V ac

Rated input current
  • For 1200-W power supply:

    • 10 A (at 100 V ac)

    • 4.9 A (at 200 V ac)

  • For 750-W power supply:

    • 8.9 A (at 100 V ac)

    • 4.3 A (at 200 V ac)

  • For 460-W power supply:

    • 5.5 A (at 100 V ac)

    • 2.6 A (at 200 V ac)

Rated input frequency
50 to 60 Hz
Rated input power
  • For 1200-W power supply:

    • 930 W (at 100 V ac)

    • 1348 W (at 200 V ac)

  • For 750-W power supply:

    • 857 W (at 100 V ac)

    • 824 W (at 200 V ac)

  • For 460-W power supply:

    • 526 W (at 100 V ac)

    • 505 W (at 200 V ac)

BTU Rating maximum
  • For 1200-W power supply:

    • 3530 BTU/hr (at 100 V ac)

    • 4600 BTU/hr (at 200 V ac)

  • For 750-W power supply:

    • 2925 BTU/hr (at 100 V ac)

    • 2812 BTU/hr (at 200 V ac)

  • For 460-W power supply:

    • 1794 BTU/hr (at 100 V ac)

    • 1725 BTU/hr (at 200 V ac)

Power supply output (per power supply)
Rated Steady-State power
  • For 1200-W power supply:

    • 800 W (at 100 V ac)

    • 900 W (at 120 V ac)

    • 1200 W (at 200 to 240 V ac)

  • For 750-W power supply:

    • 750 W (at 100 to 120 V ac)

    • 750 W (at 200 to 240 V ac)

  • For 460-W power supply:

    • 460 W (at 100 to 120 V ac)

    • 460 W (at 200 to 240 V ac)

Maximum peak power
  • For 1200-W power supply:

    • 800 W (at 100 V ac)

    • 900 W (at 120 V ac)

    • 1200 W (at 200 to 240 V ac)

  • For 750-W power supply:

    • 750 W (at 100 to 120 V ac)

    • 750 W (at 200 to 240 V ac)

  • For 460-W power supply:

    • 460 W (at 100 to 120 V ac)

    • 460 W (at 200 to 240 V ac)

top

Environmental specifications

Specification
Description
Operating temperature
10° to 35°C (50° to 95°F)
Non-operating temperature
-30° to 60°C (-22° to 140°F)
Operating relative humidity
10% to 90% non-condensing
Non-operating relative humidity
5% to 95% non-condensing
Operating altitude
3048 m (10,000 ft)
Non-operating altitude
9144 m (30,000 ft)
Acoustic noise
Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74) and declared in accordance with ISO 9296 (ECMA 109).
  • Idle:

    • LWAd - 5.5 B

    • LpAm - 37 dBA

  • Operating:

    • LWAd - 5.5 B

    • LpAm - 37 dBA

top

Technical specifications

Specification
Description
HP iLO 4 On System Management
Architecture
PCI Express based health and remote management ASIC
Video support
1920 x 1200 (16 b/p) DVR max resolution
Driver support
HP ProLiant iLO 4 Management Controller Driver Package
Memory
16MB Flash; 256MB DDR 3 with ECC (112MB after ECC and video)
Processor
Embedded ARM processor core operating at 400 MHz
HP Smart Array P420i Controller
Cache memory speed
DDR2-800 MHz with 40 or 72-bit wide bus
SAS Speed
(8) 6 Gb/s SAS links provide 4.8 GB/s maximum bandwidth
Cache memory
  • Zero Memory RAID has no cache memory

  • 40-bit 256MB ECC protected cache (battery upgrade available)

  • 72-bit 512MB BBWC or 72-bit 512MB and 1G FBWC

  • Zero Memory, Up to 2 logical volumes (8 physical drives)

Logical drives supported
Up to 64 logical drives with cache
Host memory addressing
64-bit, supporting greater than 4GB server memory space
RAID support
  • RAID 6, 6+0 (Advanced Data Guarding)

  • RAID 5, 5+0 (Distributed Data Guarding)

  • RAID 1+0 (Striping & Mirroring)

  • RAID 0 (Striping), RAID 1 (Mirroring)

top

Safety certifications

Specification
Description
FCC Rating
Class A
Normative standards
CISPR 22; EN55022; EN55024; FCC CFR 47, Pt 15; ICES-003; CNS13438; GB9254; K22;K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1
