Dell PowerEdge C6520 Barebone Node

ECS Refurbished & Tested

Request Quote

Note: Please include as much details and relevant options about the item to help us match your request with an accurate price.

*Adds to cart & you can request a quote from the cart page


Dell PowerEdge C6520 Barebone Node

The Dell EMC PowerEdge C6400 is a 2U enclosure that can handle up to four two-socket (2S) sleds. This Dell PowerEdge C6400 Chassis / Enclosure configuration can accommodate 4 Node Servers.

Dell EMC PowerEdge C-Series:

Supported Compute Sleds:

  1. Dell EMC PowerEdgeC6420 Sled CTO
  2. Dell EMC PowerEdgeC6520 Sled CTO
  3. Dell EMC PowerEdgeC6525 Sled CTO

    Product Specs for Dell DPE-C6520-CHASSIS

    Base Server Standard Capabilities

    FeatureTechnical Specification
    ChassisDell EMC PowerEdge C6400 chassis
    Nodes4 hot-swappable dual-socket compute nodes in a 2U chassis | C6520
    ProcessorUp to two 3rd Generation Intel Xeon Scalable processors per node, with up to 40 cores per processor
    • 16 DDR4 DIMM slots, supports RDIMM of 1 TB max or LRDIMM of 2 TB max, speeds up to 3200 MT/s
    • Supports registered ECC DDR4 DIMMs only
    AvailabilityHot-plug redundant drives and PSUs
    • Internal controllers: PERC H745, H750, HBA345, HBA355i, S150, H345, H350
    • Internal Boot: Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs, uSD card
    Drive baysFront bays:
    • Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) drives max 92.16 TB
    • Up to 24 x 2.5-inch SAS/SATA (HDD/SSD)/NVMe drives max 368.64 TB
    Power suppliesDual hot-plug redundant 100 - 240 V AC Platinum (2600 W, 2400 W, 2000 W, 1600 W) , 200 - 240 V AC Titanium (2600 W, 1600 W) Power supply units
    Cooling optionsAir cooling, optional processor liquid cooling
    FansNon-Hot plug fans
    DimensionsHeight: 86.36 mm (3.4 inches)
    Width: 447.04 mm (17.6 inches)
    Depth: 802.64 mm (31.6 inches)
    45.6 kg (100.53 lb) for 12 x 3.5-inch direct backplane chassis
    41.4 kg (91.27 lb) for 24 x 2.5-inch direct/NVMe backplane chassis
    35 kg (77.16 lb) for system with no backplane
    Sled height (U)1U
    • iDRAC9
    • iDRAC Direct
    • iDRAC Service Module
    • OpenManage Enterprise
    • OpenManage Power Manager plugin
    • OpenManage SupportAssist plugin
    • OpenManage Update Manager plugin
    MobilityOpenManage Mobile
    Integrations and ConnectionsOpenManage Integrations
    • VMware vCenter and vRealize Operations Manager
    • Microsoft System Center I
    • Red Hat Ansible Modules
    • BMC Truesight
    OpenManage Connections
    • IBM Tivoli Netcool/OMNIbus
    • BM Tivoli Network Manager IP Edition
    • Micro Focus Operations Manager i
    • Nagios Core
    • Nagios XI
    Integrated Security
    • TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
    • Digitally Signed Firmware
    • Chassis Intrusion Alert
    • Secure Boot
    • Secure Erase
    • Silicon Root of Trust
    • System Lockdown (requires iDRAC Enterprise or Datacenter)
    Embedded NIC1 x 1 GbE LOM riser
    Network cards1 x OCP 3.0 x16 Gen4 (for network controller)
    GPU optionsLow-profile (Half-height) 70 W GPU
    Rear Ports
    • 1 x iDRAC Direct (Micro-AB USB) port
    • 1 x Mini-DisplayPort
    • 1 x iDRAC or NIC port or RJ45
    • 1 x USB 3.0
    PCIeUp to 4 x PCIe Gen4 slots (3 x16, 1 x8) with support for SNAP I/O modules
    Supported Operating Systems
    • Canonical Ubuntu Server LTS
    • CentOS
    • Microsoft Windows Server with Hyper-V
    • Red Hat Enterprise Linux
    • SUSE Linux Enterprise Server
    • VMware ESXi/vSAN
    • Windows Preinstallation Environment (WinPE) 64-bit drivers

    Spec Sheet

    Technical Guide
