Base Standard Capabilities
| Feature | Technical Specification | |
|---|---|---|
| Processor | Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor | |
| Memory |
| |
| Storage controllers |
| |
| Drive bays | Front bays:
| |
| Power supplies |
| |
| Cooling options | Air cooling, optional processor liquid cooling | |
| Fans |
| |
| Dimensions | Height – 42.8 mm (1.7 inches) Width – 482 mm (18.97 inches) Depth – 809 mm (31.85 inches) – without bezel 822.84 mm (32.39 inches) – with bezel | |
| Form Factor | 1U rack server | |
| Embedded mgmt |
| |
| Bezel | Optional LCD bezel or security bezel | |
| OpenManage™ Software |
| |
| Mobility | OpenManage Mobile | |
| Integrations and Connections | OpenManage Integrations
| OpenManage Connections
|
| Security |
| |
| Embedded NIC | 2 x 1 GbE LOM | |
| Network Options | 1 x OCP 3.0 (x8 PCIe lanes) | |
| GPU Options | Up to three 75 W single-width GPU | |
| Ports | Front Ports:
| Rear Ports
|
| PCIe |
| |
| Operating System and Hypervisors |
| |
Technical Specs
| Feature | PowerEdge R650 | PowerEdge R640 |
|---|---|---|
| Processor | 2 x 3rd Generation Intel® Xeon® Processor Scalable Family | 2 x 2nd Generation Intel® Xeon® Processor Scalable Family |
| CPU interconnect | Intel Ultra Path Interconnect (UPI) | Intel Ultra Path Interconnect (UPI) |
| Memory | 32 x DDR4 RDIMM, LRDIMM 16 x PMem ( Intel Optane Persistent Memory 200 Series) | 24 x DDR4 RDIMM, LRDIMM 12 x NVDIMM 12 x PMem (Intel Optane Apache Pass) |
| Storage Drives | 3.5 inches, 2.5 inches- 12 Gb SAS, 6 Gb SATA, NVMe | 3.5 inches, 2.5 inches- 12 Gb SAS, 6 Gb SATA, NVMe |
| Storage Controllers | Adapters: HBA355E, H840 PERC: HBA355i, H345, H355, H745, H755, H755N BOSS- S1 adapter BOSS S2 SW RAID: S150 | Adapters: HBA330, H330, H730P,
H740P, H840, 12G SAS HBA Mini Mono:
HBA330, H330, H730P, H740P SW RAID: S140 |
| PCIe SSD | Up to 10+2 (10 x direct attach in front, and 2 x direct attach in rear) | Up to 10 (8 x direct attach, 2 x from PCIe bridge card) |
| PCIe Slots | Max 3 PCIe 4.0 | Max 3 PCIe 3.0 |
| OCP 2.0 | OCP Type 1: (Connector A) | OCP Type 1: (Connector A) |
| LOM | 2 x 1 Gb | NA |
| Networking | OCP 3.0 (x8 PCIe) | rNDC |
| Rack height | 1U | 1U |
| Power supplies | 100~240 V AC/240 V DC: 800 W, 1100
W, 1400 W DC - 48 V ~- 60 V :1100 W | AC (Platinum): 495 W, 750 W, 1100 W,
1600W, 2000W, 2400W AC (Titanium): 750 W DC: 1100 W Mix Mode/HVDC: 750 W, 1100 W |
| System management | LC 4.x, OpenManage, QuickSync2.0, Digital License Key, iDRAC Direct (dedicated micro-USB port), Easy Restore | LC 3.x, OpenManage, QuickSync 2.0, OMPC3, Digital License Key, iDRAC Direct (dedicated micro-USB port), Easy Restore, vFlash |
| Internal GPU | Up to 3 x 75 W (SW) | Up to 3 x 70 W (SW) |
| Availability | Hot-plug drives Hot-plug redundant cooling Hot-plug redundant power supplies Hot-plug BOSS S2 IDSDM | Hot-plug drives Hot-plug redundant cooling Hot-plug redundant Power supplies BOSS IDSDM |
